E&B LAB (SUPER-FINE) COMPETITION FILTER

The E&B LAB Super-Fine filter comes from the idea of creating a filter with a higher filtration power than standards.

Usually the filtration is between 250 and 350-μm.

The super-fine filter has a filtration capacity of 170-μm. To achieve this performance, we combined a 170-μm membrane to IMS holing technology.



SHAPE

BORDER: Ø 70 mm (B70)

BODY: Ø 60 mm for Ø 58 mm tamper

RIDGELESS



FILTRATION

SuperFine filtering membrane 170 µm

PERFORATION

PERFORATED AREA: Ø 40 mm

NUMBER OF HOLES: 565

The number and distribution of the holes are designed to support the filtering membrane and to balance the flow.



FINISHING

TUMBLING: Wet vibrofinishing with ceramic inserts and drying with corncob

PICKLING: Passivation and preparing of the material

ELECTROPOLISHING: smooth surface with unmatched sanitary and non-contaminating qualities is obtained.





PRODUCT CODE              HEIGHT              CAPACITY

B702TH26SF                    h.26 mm              16/18 gr

B702TH28SF                    h.28 mm              18/20 gr
